Xerox WorkCentre 3615 Service Manual

Image Quality
Phaser 3610, WorkCentre 3615 Service Manual3-40
6
Are the paper feed rolls (the rolls that are listed
among the parts considered to be the cause)
installed properly?
Go to Step 8.
Reinstall the corre-
sponding paper feed
rolls, then go to step 7.
7 Is the image printed correctly?
Troubleshooting
complete.
Go to step 8.
8
Are the paper feed rolls (the rolls that are listed
among the parts considered to be the cause in
sequence) deformed or worn out?
Replace the corre-
sponding paper feed
rolls, then go to step 9.
Go to Step 10.
9 Is the image printed correctly?
Troubleshooting
complete.
Go to step10.
10
Reseat the Paper Cassette.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 11.
11
Load the unopened (or sealed and stored under
humidity control) and recommended paper, and
then perform a test print.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 12.
12
Reset the Paper Cassette side guide.
Is the image printed correctly?
Troubleshooting
complete.
Go to step 13.
13
Reseat (REP 3.4 Transfer Roller Assembly).
Is the image printed correctly?
Troubleshooting
complete.
Go to step 14.
14
Reseat the Fusing Assembly.
Is the image printed correctly?
Troubleshooting
complete.
Replace (REP 3.5 Fus-
ing Assembly).
Troubleshooting Procedure (Continued)
Step Actions and Questions Yes No

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
