Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-7
Parts List 1.1 Covers (3610)
Item Description Part Number
1. Front Cover
2. Interlock Actuator
3. Interlock Spring
4. Interlock Holder
5. Front Cover Assembly (with 1-4)
6. Label MSI Instruction
7. Front Cover Assembly (with 5, 6) (REP 1.2) 604K85880
8. Lower Rear Cover (REP 1.8) 848E82672
9.
13. Left Side Cover (REP 1.7) 848E82792
14. Top Front Cover
15. Cover Extension
16. Cover Extension 2nd
17. Top Front Cover Assembly (with 14, 18) (REP 1.4) 604K84920
18. Logo Plate Assembly
19.
20. Right Side Cover (REP 1.6) 604K84941
21. Top Cover Assembly (with 22, 23) (REP 1.4) 848K62885
22. Top Cover (Mid)
23. Exit Cover (Mid)
24.
25.
26. Rear Cover Assembly (REP 1.5) 848K70060
27. Spring-earth DTS Out
28. Duplex Chute Assembly (PL 2.4) (REP 2.1) 054K48100
95. Top Front Cover Extension Assembly (with 15, 16) (REP 1.3) 604K77391
97. Cover Assembly Front (with 7,18)
98. Left Side Cover Assembly (with 13, 19)

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
