Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-9
Parts List 1.2 Covers (3615)
Item Description Part Number
1. Front Cover
2. Actuator Interlock
3. Spring Interlock
4. Holder Interlock
5. Front Cover Assembly (with 1-4)
6. Label MSI Instruction
7. Front Cover Assembly (with 5, 6) (REP 1.2) 604K85890
8. Lower Rear Cover (REP 1.18) 848E82672
9.
10.
11.
12.
13. Left Side Cover (REP 1.11) 848E82815
14. Top Front Cover
15. Cover Extension
16. Cover Extension 2nd
17. Top Front Cover Assembly (with 14, 18) (REP 1.3) 604K84931
18. Logo Plate
19.
20. Right Side Cover (REP 1.13) 848K68342
21. Top Cover Assembly (with 22, 23) (REP 1.15) 848K62912
22. Top Cover
23. Exit Cover
24.
25.
26. Rear Cover Assembly (PL 1.3) (REP 1.8) 604K85650
27. IIT Lower Right Cover (REP 1.13) 848E82901
28. IIT Right Inner Cover (REP 1.14) 848E89270
29. Earth Spring
30. Duplex Chute Assembly (PL 2.4) (REP 2.1) 054K48100
31. Upper Left Side Cover (REP 1.11) 848E89213
32. Upper Right Side Cover (REP 1.13) 848E89231
95. Kit Cover Assembly Extension (with 15, 16) (REP 1.3) 604K85900

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
