Xerox WorkCentre 3615

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-11
Parts List 1.3 Rear Cover Assembly
Item Description Part Number
1. Rear Cover Assembly (REP 1.5) (REP 1.18) 604K85650
2. Top Rear Cover
3. Rear Cover Latch
4. Rear Latch
5. Duplex Chute (PL 2.4) (REP 2.1) 054K48100
6. Rear Latch Spring
7. Rear Strap 868E76893
8. Rear Guide Harness
9. Rear Fan
10. Rear Fan Screw
