Xerox WorkCentre 3615

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-17
Parts List 2.1 Registration
Item Description Part Number
1. Duplex Lower Chute Assembly (with 2, 3)
2. Duplex Lower Chute
3. Spring Wc Il
4. Interlock Harness Assembly
5.
6. Transport Assembly (REP 2.2) 059K79334
7.
8. Registration Out Earth Plate
9. Rear Fan Connector Holder
10.
11. CST Stopper (REP 2.9) 803E13351
97. (3610) Rear Interlock Assembly (with1, 4)
(3615) Rear Interlock Assembly (with1, 4) (REP 2.10)
604K85740
604K85750
