Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-19
Parts List 2.2 Transport Assembly
Item Description Part Number
1. Registration In Chute
2. Support Roll 2
3. Registration Spring
4. Registration Clutch (REP 2.6) 121K51870
5. Registration Earth Bearing ZA
6. Rubber Roll Assembly ZA (REP 2.7) 059K74580
7. Right Registration Bearing
8. Registration Pinch Roll Assembly
9. Registration Out Chute
10. Lower Feed Chute
11.
12. Registration Chute
13.
14. Registration Shutter Sensor (REP 2.8) 055E60433
15.
16.
17.
18. Registration Actuator MSI
19. Actuator Spring ZA
20. Actuator
21. No Paper Tray Actuator
32. Chute Guide
33. Support Roll 2
34.
35. No Paper Tray Actuator
36. Registration Pinch Roll Shaft
37. Registration Pinch Roll
38. Center Bearing
39. Support Roll 2
40.
41. Registration Chute Assembly (with 12, 18-21, 32-35)
99. Feeder Assembly Kit (REP 2.3)
