Xerox WorkCentre 3615

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-23
Parts List 2.4 Duplex Chute
Item Description Part Number
1. Duplex Bearing
2. Duplex Roll Assembly
3. Earth Spring
4. Duplex Gear
5. Duplex Pinch Roll
6. Duplex Pinch Roll Spring
7. Duplex In Chute
8. Transport Chute
9.
10.
11.
12. Duplex Chute Assembly (with 1-8,13,14) (REP 2.1) 054K48100
13. BTR Spring Cap
14. BTR Spring
