Xerox WorkCentre 3615

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-41
Parts List 4.1 Drive
Item Description Part Number
1. Main Drive Assembly (REP 4.1) 007K18903
2. Drive Exit Out Holder Assembly (with 7-9) (REP 4.2) 007K18912
3. Drive Exit In Holder Assembly S3 (with 6) (REP 4.3) 007K18931
4. Duplex Gear Holder (REP 4.4) 019E83450
5. Duplex In Gear (REP 4.4) 807E38660
6. Exit Assembly Clutch T21
7. Assembly Invert Clutch T24
8. Gear
9. Gear
