Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-43
Parts List 4.2 NOHAD
Item Description Part Number
1. LVPS Fan Assembly 127K66001
2. Band Cable
3. Right Front Link (REP 4.5) 012E18133
4. Left Front Link (REP 4.5) 012E18143
5. Right Shaft Link
6. Left Shaft Link
7. Link Connector 012E18172
8. Link Interlock
9. Right Xerographic Stopper Assembly
10. Left Xerographic Stopper Assembly
11. Interlock Spring
12. Foot
97. Foot Assembly 604K77650

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
