Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-47
Parts List 5.2 Electrical (3615)
Item Description Part Number
1. ESS Plate Window
2. ESS PWB (REP 5.1) 960K69985
3. ESS Top Plate
4. ESS Housing
5. LVPS PWB 110
LVPS PWB 220 (REP 5.3)
604K85611
604K85621
6. LVPS Plate
7.
8. Front USB Harness Assembly
9. FAX Guard
10. FAX PWB Assembly (REP 5.4) 960K67970
11. Front USB Assembly (REP 5.5) 952K08202
12. ESS Cover Assembly (with 1, 13-15) (REP 5.2) 848K82861
13. Screw
14. E-Ring
15. ESS Cover
16. Cable Clamp
17. Wireless Adaptor 676K21281
18.
19. SD Card 497K13650
20. Speaker Cover
21. Speaker Assembly

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
