Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-57
Parts List 7.2 Tray 1/Optional Tray 550-Sheet Feeder (2/4)
Item Description Part Number
1. No Paper Sensor Cover
2. No Paper Sensor (REP 7.9) 930W00123
3. Optional No Paper Harness Assembly
4. Upper Chute- Optional 550
5. Nudger Bearing
6. Nudger Assembly Support
7. One-way Feed Clutch
8. Feed Gear
9.
10. Nudger Idler Gear
11. No Paper Actuator
12. Nudger Shaft
13. Feed Roll Assembly (3 pack) (REP 7.11) 604K11192
14. Nudger Gear
15. Lower Chute Optional 550
16. Feed Shaft Assembly 550
17.
18.
19. Pinch Chute Assembly 550
20. Registration Clutch Assembly (REP 7.10) 121K48670
21. Take Away Roll Assembly (REP 7.14) 059K71770
22. Earth Plate
23. Nudger Spring Bracket
24. Sensor Cover Harness
25. Gear Shaft
26. Optional Feeder Gear 550
27. Optional Nudger Spring
