Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-59
Parts List 7.3 Tray 1/Optional Tray 550-Sheet Feeder (3/4)
Item Description Part Number
1. IOT Cassette Assembly (With 2-36,38) 050K71211
2. Plate Bottom CST Mat X
3. Retard Holder Assembly CST (With 4-7)
4. Feed Roll Assembly
5. Friction Clutch
6. Retard Shaft CST
7. Retard Holder CST
8. Right Side Guide Assembly
9. Left Side Guide Assembly
10. Pinion Gear
11. Cover BTM Lock 550
12. Back BTM Lock 550
13. Pinion Gear BTM Lock
14. Gear Lever BTM Lock
15. Lever BTM Lock
16. Gear 40 BTM Lock
17. Spring BTM Lock
18. Spring Lock Pb
19. Actuator Lock Pb L
20.
21. Spring BTM Up 550 A4
22. Retard Spring Holder
23. Retard Spring Cst
24. Rack Left Up Pb 550
25. Housing Base 550
26. Lever Ext End 550
27. End Guide 550
28. Housing End 550
29.
30. Tray Handle 550
31.
Pad Pb
32. Instruction Label- D
33. Instruction Label Ad
34. Tray Label
35. Label
36. Handle Gd Sd
37. Retard Assembly Roll Instruction
38. End Guide Handle
98. Feed Rolls (With 4*3 Pcs) (REP 7.11) 604K11192
99. Retard Roll Assembly Kit (With 3,37) (REP 7.13) 604K78360
100. Dust Cover 848E93660
