Xerox WorkCentre 3615 Service Manual

Parts List
Phaser 3610, WorkCentre 3615 Service Manual 5-65
MFP 604K85860 DADF Top Cover Assembly PL 6.1 NA
960K67512 Optional Tray PWB Assembly (550) PL 7.1 REP 7.1
007K18020 Drive Assembly (550) PL 7.1 REP 7.6
005K83210 Feed Clutch Assembly (550) PL 7.1 REP 7.7
050K71211 Tray Assembly (550) PL 7.1
059K86170 Feeder Assembly (550) PL 7.1 REP 7.8
803E10840 Stopper CST (550) PL 7.1 NA
SFP
MFP
059K82011
059K82021
Feeder Assembly (w/o tray) PL 7.1 REP 7.11
930W00123 No Paper Sensor (550) PL 7.2 REP 7.9
121K48670 Registration Clutch Assembly (550) PL 7.2 REP 7.10
059K71770 Take Away Roll Assembly (550) PL 7.2 REP 7.14
050K71210 IOT Cassette Assembly (550) PL 7.3 NA
604K11192 Feed Rolls (550) PL 7.2 REP 7.11
604K78360 Retard Roll Assembly Kit (550) PL 7.3 REP 7.12
930W00123 Pre-Registration Sensor (550) PL 7.4 REP 7.13
SFP/MFP Part Number Part Description PL Number REP Number

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
