Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-11
3. Print Info
•Info Page
•Print Settings
3. Scanner Maintenance
•White Balance
–Auto Adjust (FB)
– Auto Adjust (DADF)
• Shading Parameter
– Coeff FB RED
– Coeff FB Green
– Coeff FB Blue
– Coeff FB Grey
–Coeff DADF RED
– Coeff DADF Green
–Coeff DADF Blue
– Coeff DADF Grey
–Target RED
– Target Green
–Target Blue
–Target Grey
• Registration Parameter
–Regi FB Lead
–Regi FB Side
– RegiDADFLead (Front)
– RegiDADFSide (Front)
–RegiDADFLead (Back)
– RegiDADFSide(Back)
– RegiDADFLead (FrontDUP)
• Auto Registration
•Sensor Parameter
– Feed Sensor
•Vertical Scan Mag
–Mag FB Color
–Mag FB Grey
–Mag DADF Color
– Mag DADF Grey
• Test Pattern
–Pattern No.
3. Adjust Touch-
screen...
Printer Diag (3610 / 3615) Fax / Scanner Diag (3615) Panel Diag (3615)

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
