Xerox WorkCentre 3615 Service Manual

Wiring
Phaser 3610, WorkCentre 3615 Service Manual 7-41
Notations Used in the Wiring Diagrams
The following table lists the symbols used in the wiring diagrams.
Symbol Description
Denotes a Plug.
Denotes a Jack.
Denotes Pin yy and Jack yy of the connector Pxx and Jxx.
Denotes a Jumper Point (JPxxx/xxx). Each end of the Jumper connection has
a numeric designation.
Denotes the parts.PL X.Y.Z implies the item “Z” of plate (PL) “X.Y” in Parts
List.
Denotes functional parts attached with functional parts name.
Denotes the control and its outline in the PWB.

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
