Xerox WorkCentre 3615 Service Manual

Wiring
Phaser 3610, WorkCentre 3615 Service Manual 7-43
Denotes a Safety Interlock Switch.
Denotes an On-Off Switch (single-pole, single-throw switch).
Denotes an On-Off Switch (Temperature - normally close).
Denotes an NPN Photo-transistor.
Represents an interconnection between parts using wiring harness or wire.
Represents an interconnection which differs according to the specifications.
Represents an interconnection between parts using a conductive part such
as a Plate Spring.
I/L +24 VDC Denotes DC voltage when the Interlock Switch in the MCU PWB turns On.
+5 VDC
+3.3 VDC
Denotes DC voltage.
SG Denotes signal ground.
AG Denotes analog ground.
RTN Denotes return.
Symbol Description

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
