Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-16
071 016 Option Feeder 3 Motor [(Tray 4)MOTOR ASSY OPTION] (Half)
071 017 Option Feeder 3 Motor [(Tray 4)MOTOR ASSY OPTION] (Low)
071 018 Option Feeder 1 Feed Clutch [(Tray 2)CLUTCH ASSY OPT FEED] (Auto OFF)
071 019 Option Feeder 2 Feed Clutch [(Tray 3)CLUTCH ASSY OPT FEED] (Auto OFF)
071 020 Option Feeder 3 Feed Clutch [(Tray 4)CLUTCH ASSY OPT FEED] (Auto OFF)
071 021 Option Feeder 1 Take Away Clutch [(Tray 2)CLUTCH ASSY REGI]
071 022 Option Feeder 2 Take Away Clutch [(Tray 3)CLUTCH ASSY REGI]
071 023 Option Feeder 3 Take Away Clutch [(Tray 4)CLUTCH ASSY REGI]
093 001 Toner Dispense Motor [MOTOR DISP] (Normal)
093 002 Toner Dispense Motor [MOTOR DISP] (Half)
Motor Test Parameter Table
Chain Link Component
