Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-40
116-316
DIMM RAM Error
Reseat Memory
Error 116-316
Power Off/On
<ESS DIMM Slot RAM W/R Check Fail>
Cause:
Detected by DIMM Slot RAM W/R Check at the
time of initialization.
FIP 1. 301
116-317
Controller Error
Power Off/On
Error 116-317
Power Off/On
<ESS ROM Check (Main) Fail>
Cause:
Main Program ROM checksum error.
FIP 1. 302
116-320
DIMM Error
Reseat Memory
Error 116-320
Power Off/On
<ESS DIMM Slot RAM Error>
Cause:
Occurs when unusable DIMM is inserted in DIMM
slot in initialization processing at power-on.
FIP 1. 301
116-323
NVRAM Error
Power Off/On
Error 116-323
Power Off/On
<ESS NVRAM1 W/R Check Fail>
Cause:
Detected by master NVRAM W/R check.
FIP 1. 303
116-324
Controller Error
Power Off/On
Error 116-324
Power Off/On
<ESS Illegal Exception>
Cause:
CPU illegal exception.
FIP 1. 303
116-325
NVRAM Error
Power Off/On
Error 116-325
Power Off/On
<ESS NVRAM3 W/R Check Fail>
Cause:
It detects with the W/R check of a Slave NVRAM
at the time of initialization.
FIP 1. 304
116-326
NVRAM Error
Power Off/On
Error 116-326
Power Off/On
ESS NVRAM2 W/R Check Fail
Cause:
Detected by master NVRAM W/R check.
FIP 1. 304
116-327
Controller Error
Power Off/On
Error 116-327
Power Off/On
<ESS Instruction Cache Error>
Cause:
CPU instruction cache error.
FIP 1. 305
Status
Code
(3610)
LCD Message Name/Description of Error FIP

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
