12 SYSTem Subsystem
530 N1911A/1912A P-Series Power Meters Programming Guide
DISP[:WIND[1]|2]:FORM Agilent N1911A:
Upper - digital
Lower - analog
Agilent N1912A:
Upper - digital
Lower - digital
Display format
DISP[:WIND[1]|2]:MET:LOW –70.000 dBm Analog meter lower limit
DISP[:WIND[1]|2]:MET:UPP +20.000 dBm Analog meter upper limit
DISP[:WIND[1]|2|][:NUM[1]|2]
:RES
3 Window resolution
DISP[:WIND[1]|2]:SEL[1]|2 upper window Window selected
DISP[:WIND[1]|2][:STAT] ON Both windows enabled on display
SENSe[1]|2:TRAC:LIM:UPP DEF Maximum power
SENSe[1]|2:TRAC:LIM:LOW DEF Minimum power
FORM[:READ]:BORD normal Binary order
FORM[:READ][:DATA] ascii Data format
INIT[1]|2:CONT *RST: OFF
SYS:PRES ON
Power Meter in idle state
Power Meter in wait for trigger state
MEM:TABL:SEL not affected Active sensor calibration table
OUTP:REC[1]|2:FEED not affected Previous measurement
OUTP:REC[1]|2:LIM:LOW –150 dBm Minimum scaling value
OUTP:REC[1]|2:LIM:UPP 20 dBm Maximum scaling value
OUTP:ROSC:STAT OFF 50 MHz reference disabled
OUTP:TRIG:STAT OFF Trigger output signal disabled
[SENS[1]]|SENS2:AVER:COUN 4 Filter length
[SENS[1]]|SENS2:AVER:COUN:AUTO ON Auto-filtering enabled
[SENS[1]]|SENS2:AVER:SDET 1 Step detection enabled
[SENS[1]]|SENS2:AVER[:STAT] ON Averaging enabled
[SENS[1]]|SENS2:AVER2:COUN 4 Video average length
[SENS[1]]|SENS2:AVER2[:STAT] ON Video averaging enabled
[SENS[1]]|SENS2:BAND|BWID:VID OFF Sensor video bandwidth set to off
[SENS[1]]|SENS2:CORR:CFAC|
GAIN[1][:INPut][:MAGNitude]
100.0 % Calibration factor
Command Setting Comments
