Optional: Trimming the dust bag and connector
If you are feeling confident using the intersecting and trimming tools, you
may want to tidy up the rear of the vacuum cleaner by intersecting and
trimming the dust bag and cable connector.
Remember to intersect all dust bag surfaces with the body surfaces, and the
connector surfaces with the dust bag surfaces.
TIP Delete the mirrored surfaces, then do the intersecting and trimming. When
the trimming is complete, mirror the surfaces to create the completed model.
Save your work
1 Choose File > Save As to save the current scene.
Part 8: Completing the Model | 389
