Intersecting and Trimming the air vents
You will now intersect and trim the three extruded surfaces with the upper
surface of the vacuum body.
1 With the three surfaces still selected, choose Surface Edit > Create
CurvesOnSurface > Intersect .
340 | Chapter 6 Modeling a Vacuum Cleaner
