Instructions for use Zeus Infinity Empowered SW 2.n 101
Startup
Displaying the test results
Test results
Calling up the test results:
z Touch the Test results tab (A).
All results of the last test are displayed and saved
until the next test or a restart.
The test result is displayed in color:
Test info
Calling up the test info:
z Touch the Test info tab (A) or View details tab
(B).
All faults from the self test or leak test are listed.
The user receives the following information about
troubleshooting:
– Fault (C)
– Cause and remedy (D)
– Graphic presentation of the system compo-
nents
In addition to the image, important system data is
displayed:
– Central supply pressure and cylinder pressure
– Leaks and compliance, with the time of the last
measurement
– Battery capacity
– Anesthetic agent quantity in the DIVA metering
module
316
Green test successful
Red test unsuccessful
Gray not tested
Test details
A
319
SEVISO
Test details
A
B
C
D
