Instructions for use Zeus Infinity Empowered SW 2.n 401
Technical data
Central gas supply
Pneumatic connections Central gas supply (CS): O2, N2O, Air.
Backup gas cylinders: 2 cylinders, 3 liters each (O
2,
Air or N2O)
Anesthetic gas scavenging system.
Vacuum central supply (optional).
Anesthetic gas scavenging system Nominal nozzle diameter 27 mm or ISO cone
30 mm; (according to EN 1281-1)
Required composition of gases
O
2, Medically pure (Europ. Pharmacopoeia)
Minimum O
2 concentration: 99.5 %
N
2O Medically pure (Europ. Pharmacopoeia)
Air Dew point: >5 °C below ambient temperature at
0.5 MPa (5 bar)
Oil content: <0.1 mg/m
3
Particles: Dust-free air; filtered with pore size
<1 µm
Required input pressures (central supply) for O2,
N
2O and Air
Nominal pressure range 270 to 690 kPa
Pressure range with guaranteed function (not
specified).
180 to 1000 kPa
At an input pressure of <180 kPa and >1000 kPa
the device and any other similarly designed devices
connected to the central supply can no longer me-
ter gases.
Inspiratory O2 concentration
Insp. O2 concentration Max. deviation
≤35 Vol.%
>35 Vol.% ≤60 Vol. %
>60 Vol.%
–3 Vol.%
–5 Vol.%
–7 Vol.%
