Instructions for use Zeus Infinity Empowered SW 2.n 141
Operation
Safety concept
When a pump is operated by Zeus IE for the first
time or after a change of drug, a dialog window (A)
appears showing the parameters which determine
metering.
If the application time of the bolus is >180 seconds,
this dialog window also appears. The value of the
bolus rate appears in yellow.
Controls for IV
By connecting the IV system IVenus to Zeus IE,
operation of the Module DPS syringe pumps is con-
trolled via the screen. Zeus IE can control up to 4
Module DPS syringe pumps.
Module DPS syringe pumps are controlled from:
A The Infusion settings dialog window for all set-
tings
Or
B The field for IV control in the lower part of the
screen for direct access to key functions
The gas supply is then displayed in the data
modules area.
During operation, the Module DPS syringe pumps
are controlled via the IV control field.
476
WARNING
Risk of patient injury
To eliminate the risk of incorrect settings and
ensure the patient's safety, the patient data
and/or IV settings must be checked on the sy-
ringe pump and on Zeus IE.
1
A
345463
1 2 3 4
A
B
Infusion settings
ATRAC
3.00
Inf mg/kg/h
Start bolus
C
D
1
