Dräger Zeus Infinity Empowered - Airway Pressure Paw

Monitoring
192
Instructions for use Zeus Infinity Empowered SW 2.n
Airway pressure Paw
The Paw parameter box displays:
– PIP (peak pressure)
– P
mean (mean pressure)
– PEEP (positive end-expiratory pressure)
Additionally after touching the Display all button
(prerequisite: Display all button has been config-
ured, see page 332):
– Pplat (plateau pressure)
– currently set alarm limits
Setting the amplitude of the Paw scale
z Touch the Paw button (A).
The Paw page displays:
B The current Paw curve
C Paw scale (scaling of the Paw curve in relation
to the amplitude)
D The button opens the Alarms > Alarm lim-
its > Ventilation dialog window for alarm limit
setting.
