Instructions for use Zeus Infinity Empowered SW 2.n 413
Technical data
Anesthetic gas metering modules
Maximum tipping angle / sloped position During operation in device: 5° max.
During storage/transport: Any
Filling volume Total volume: 315 mL
Between max./3rd mark: 250 mL
Anesthetic agent loss <1.0 mL liquid in 24 hours in storage or transport.
Data communication
Removable media USB ports
Serial ports COM1 and COM2
Connector 9-pin, Sub-D
Pin allocation:
1 CD (carrier detect)
2 RX (receive)
3 TX (transmit)
4 DTR (data terminal ready)
5 GND (ground)
6 DSR (data set ready)
7 RTS (request to send)
8 CTS (clear to send)
9 RI (ring indicator)
Data protocol MEDIBUS
Settings:
Speed 1200, 2400, 4800, 9600, 19200, 38400 baud
Parity Even
Number of data bits 8
Number of stop bits 1
Connections for IV system (optional)
Standard RS232:
Connector 9-pin, Sub-D
Network ports RJ-45 Cat. 5
