Instructions for use Zeus Infinity Empowered SW 2.n 193
Monitoring
Anesthetic agent
The Volatile agent parameter box display can be
varied:
Display 1
– Inspiratory (in) and expiratory (et) values of the
anesthetic agent, of N
2O and O2
Display 2
– Inspiratory (in) and expiratory (et) values of the
anesthetic agent
– xMAC (MAC* multiple)
If a second anesthetic agent is measured, it is dis-
played instead of N
2O.
An age-adjusted MAC multiple is used,
see page 114.
Setting the amplitude of the Volatile agent scale
z Touch the Volatile agent button (A).
The Volatile agent page displays:
B The current curve for the volatile anesthetic
agent
C VA scale (scaling of this curve in relation to the
amplitude)
D The button opens the Alarms > Alarm lim-
its > Anesth. dialog window for alarm limit set-
ting
230
* MAC – Minimum Alveolar Concentration
