Dräger Zeus Infinity Empowered - Filling During Operation; Quik Fil Sevoflurane Safety Filling System

Assembly and preparation
84
Instructions for use Zeus Infinity Empowered SW 2.n
Quik Fil sevoflurane safety filling system
The safety filling system consists of the following
components:
A Anesthetic-specific filling device on the DIVA
metering module
B Anesthetic-specific adapter on the anesthetic
agent bottle.
Filling during operation
1 Press the Ventilate reservoir (A) button.
The DIVA metering module is ventilated for ap-
prox. 1 minute. No anesthetic agent vapor es-
capes into the environment during filling.
2 Unscrew the cap (B) from the bottle adapter.
The bottle adapter must be positioned firmly
and tightly on the anesthetic agent bottle and
must be undamaged.
053332
A
B
MixGas settings
A
060
CAUTION
Increased occupational exposure
With a leaky connection between the bottle
adapter and anesthetic agent bottles, anesthetic
agent vapor can escape.
B
