Instructions for use Zeus Infinity Empowered SW 2.n 379
Cleaning, disinfection, and sterilization
9 Attach the breathing system (F) to the ventilator
vertically from above.
10 Lock the breathing system with the two lateral
twist locks (G) by turning as far as they will go.
Assembling the CO2 absorber
Filling the CO2 absorber and installing the IBF
absorber filter
1 Push the insert (A) into the CO
2 absorber com-
pletely.
Recommendation:
Use only Drägersorb 800 Plus or
Drägersorb Free! Do not use any powdered lime
since an increased dust yield can impair the func-
tionality of Zeus IE!
2 Insert the IBF absorber filter (B) in such a way
that the writing is legible and the filter engages.
3 Attach CO
2 absorber (C) to the breathing sys-
tem from the bottom and turn clockwise as far
as it will go.
IBF absorber filter
Drägersorb CLIC disposable absorber
1 Shake the disposable CO
2 absorber before in-
serting, e.g. by inverting it several times to
loosen the soda lime.
2 Remove the seal from the new disposable CO2
absorber.
244
NOTE
Make sure the soda lime does not dry out.
027
CAUTION
Fill CO2 absorber with fresh soda lime to the up-
per mark. Otherwise, operational reliability may
be restricted.
F
G
A
B
C
WARNING
If the absorber filter, HME filter or the filters at
the device have been forgotten, it may be that
the blower has been contaminated. It is rec-
ommended to reprocess the ventilator before
changing the patient.
069
D
