Instructions for use Zeus Infinity Empowered SW 2.n 407
Technical data
Inspiratory flow 180 L/min +10 % maximum
Resulting from the VT or P
insp and Ti settings
Trigger 0.3 to 15 L/min
Resolution:
0.3 to 1 L/min: 0.1 L/min
1 to 15 L/min: 1.0 L/min
Breathing system
Total volume (without breathing hoses) approx. 2.0 liter with absorber container
Compliance (without breathing circuit) With MAN/SPON ventilation: approx. 2 mL/hPa
With automatic ventilation: <0.2 mL/hPa
Absorber volume 1500 mL
"Drägersorb 800 plus" soda lime binds
approx. 150 liters of CO
2
Safety pressure control valve 85 ±10 hPa
Patient connections ISO cone 22 mm
Breathing system leak <150 mL/min at 30 hPa, standardized to BTPS
conditions
Pressure control valve APL Setting range: 5 to 70 hPa
Accuracy: ±15 % of set value or ±3 hPa at 20 L/min
Auxiliary valve –18 hPa ± 3.5 hPa
Ventilation (Cont.)
