Instructions for use Zeus Infinity Empowered SW 2.n 133
Operation
1 Screw sample line (A) onto the Luer-Lock of the
elbow and connect it to the Luer-Lock of the
CO
2 water trap on Zeus IE.
When using elbows without sample line con-
nection point:
z Place the T-piece with filter directly on the
elbow.
Or
z Use the Luer-Lock of a filter if necessary.
2 Connect the fresh-gas hose (B) of the Bain sys-
tem to the external fresh-gas outlet.
3 The anesthetic gas scavenging hose of the non-
rebreathing system can be connected to the Y-
piece (C) of the breathing system of Zeus IE.
z Observe the instructions for use of the Bain sys-
tem.
Directing fresh gas to the external outlet
1 Touch the External FG outlet tab (A). The color
turns yellow.
The following message appears: MixGas will
be switched to Fresh-gas control automati-
cally.
2 Confirm with rotary knob.
3 Set fresh-gas values.
Settings:
–O
2 fresh-gas concentration FG O2 (B)
– Fresh-gas flow Flow (C)
– Fresh-gas concentration of the anesthetic
agent FG DES, FG ISO, FG SEV (D)
4 Touch the therapy control of the parameter.
5 Use the rotary knob to set and confirm the
value.
The set values are transferred to the system.
After closing the Ventilation settings dialog win-
dow, the External fresh-gas outlet mode is dis-
played in the lower part of the screen.
NOTE
If the Ext. fresh-gas outlet is switched on when
in the Auto control control mode, the Zeus IE ac-
tivates the Fresh-gas control control mode auto-
matically.
470
Ventilation settings
A
Ext. fresh-gas outlet
Check fresh-gas settings.
B
CD
MixGas will be switched
to Fresh-gas control au-
tomatically.
344
External fresh-gas outlet
