Instructions for use Zeus Infinity Empowered SW 2.n 67
Assembly and preparation
1 Turn the CO2 absorber (A) counterclockwise
and remove downwards.
2 Remove the IBF absorber filter (B) using the re-
cessed handles in the filter.
3 Empty out the used soda lime and dispose of
according to the soda lime instructions for use.
4 Fill the CO
2 absorber with fresh soda lime up to
the upper mark.
5 Insert new IBF absorber filter. Only use undam-
aged filters, as exterior damage to the filter de-
creases protection!
6 Attach CO
2 absorber to the breathing system
from the bottom and turn clockwise until it en-
gages.
Using disposable CO2 absorbers
Optional CLIC adapter
The CLIC adapter makes it possible to use
Drägersorb CLIC 800 Plus or
Drägersorb CLIC Free disposable CO2 absorbers,
see instructions for use of disposable CO2 absorb-
ers.
No IBF filter is required if using the recommended
cartridges (dust filter is already integrated in the
cartridge).
Fitting the CLIC adapter
z Insert the CLIC adapter into the breathing sys-
tem from below and turn clockwise as far as it
will go. Make sure that the unlock button (A)
is facing the front and visible to the
user.
018
A
B
005
A
B
