Instructions for use Zeus Infinity Empowered SW 2.n 131
Operation
Set ranges and default values for the ventilation modes
Set point Vol. Ctrl. AutoFlow /
Volume Control
Pressure Control Pressure Support MAN/SPON
VT VT (measured) ––– ––– –––
P
insp ––– Pplat ––– –––
T
i X X ––– –––
T
e X X ––– –––
PEEP X X ––– –––
∆Psupp X X X –––
Slope X
1)
1) Only applies to Vol. Ctrl. AutoFlow.
XX–––
CPAP ––– ––– X/PEEP X
Trigger X
1)
XX–––
––– Is not adopted.
X Is adopted
Ventilation parameter Setting range Factory default value
Neo Ped1 Ped2 Adult1 Adult2
Tidal volume VT [mL] 20 to 1500 30 150 300 600 700
Respiratory rate RR [1/min] 3 to 80 30 25 20 12 10
Inspiration time T
i [sec.] 0.2 to 10 depending on RR, I:E
RRmin [1/min] 12 6 6 3 3
I:E ratio 4:1 to 1:4 1:1 1:2 1:2 1:2 1:2
Maximum airway pressure P
max [mbar] 8 to 70 15 20 40 40 40
CPAP [mbar] Off, 3 to 10 Off Off Off Off Off
Positive end expiratory pressure PEEP
[mbar]
Off, 3 to 35 Off Off Off Off Off
Inspiration pressure P
insp [mbar] 3 to 70 10 15 15 15 15
Pressure support ∆Psupp [mbar] 0 to 70 0 0 0 0 0
Pressure rise time Slope [sec.] 0 to 2 0 0 0 0 0
Flow trigger sensitivity Trigger [L/min] 0.3 to 15 3 3 6 6 6
