Technical data
422
Instructions for use Zeus Infinity Empowered SW 2.n
Invasive blood pressure (IBP)
Measuring principle Resistive pressure transducer
Resolution 1 mmHg
Measuring range –50 to 400 mmHg
Frequency ranges DC up to 8 Hz,
DC up to 16 Hz and
DC up to 32 Hz (adjustable)
Accuracy ±1 mmHg or ±3 %, excluding the pressure trans-
ducer
Zero calibration range ±200 mmHg
Transducer specifications Permitted pressure transducers with a resistance of
200 to 3000 Ω and an equivalent pressure sensitiv-
ity of 5 µV/V/mmHg ±10 %
Electrical specifications Type CF as per IEC 60601-1
Defibrillation protection according to IEC 60601-2-34
Wedge measurement
Pressure measuring range 10 to 120 mmHg
Deflection rate 6.25 to 50 mm/s
