Dräger Zeus Infinity Empowered - Disassembly; Disassembly Sequence; Observe before Disassembling

Cleaning, disinfection, and sterilization
358
Instructions for use Zeus Infinity Empowered SW 2.n
Disassembly
Observe before disassembling
z Switch off the device and accessory devices
and remove their mains plugs.
Disassembly sequence
1 Unscrew the sample line and dispose of.
2 Remove the water trap.
3 Remove the CO
2 absorber:
z The CLIC absorber (disposable)
or
z The reusable CO
2 absorber:
4 Remove the breathing bag.
5 Disassemble the breathing circuit and the fil-
ters.
6 Remove the breathing system.
– Unlock the lateral twist locks.
– Withdraw the assembled breathing system
vertically upwards.
7 Unscrew the CLIC adapter (optional).
8 Remove the flow sensors.
– Loosen and pull out the expiratory port.
– Loosen and pull out the inspiratory port.
– Remove the flow sensors.
9 Remove the upper housing of the breathing
system.
– Open the five quick-release screws by turn-
ing them 90° counterclockwise.
– Lift off the upper housing of the breathing
system.
10 Screw off the APL valve.
11 Remove the TurboVent 2 blower module.
– Unscrew the CO
2 absorber from the
breathing system.
– Remove and dispose of the soda lime
dust filter (optional).
– Empty the CO
2 absorber.
– Remove the absorber insert from the ab-
sorber container. Leave the inner and
outer sealing rings on the absorber in-
sert.
WARNING
Risk of damage to breathing system
If the APL valve is not disassembled before
the breathing system is reprocessed, this can
lead to leakages in the breathing system.
Always remove the APL valve prior to reproc-
essing.
NOTE
To prevent accidental penetration of soda lime
into the breathing system, do not transport the
breathing system with a filled reusable CO2 ab-
sorber.
