Instructions for use Zeus Infinity Empowered SW 2.n 381
Cleaning, disinfection, and sterilization
Connecting anesthetic gas receiving system
(AGS)
The anesthetic gas scavenging system (AGSS)
must conform to ISO 8835-3 and ISO 80601-2-13.
5 Attach the transfer hose to the waste gas nozzle
(E) at the lower rear section of the device and to
the side nozzle (E) of the receiving system.
6 Plug the suction hose onto the nozzle (F) of the
receiving system.
7 Connect the plug (G) to the suction hose.
8 Make sure the second nozzle on the receiving
system (H) is closed off.
z Follow the instructions for use of the anesthetic
gas receiving system (AGS).
Removing the endotracheal suction sys-
tem
1 Insert the overflow protection float (A) into the
riser pipe until it engages. The ball is freely to
move and does not fall out.
2 Attach the silicone sleeve (B) uniformly to the
cover of the secretion collecting bottle.
3 Put the secretion collecting bottle into the inner
sleeve, put the rinsing bottle into the outer
sleeve.
If you are using the VacuSmart disposable con-
tainer, observe the relevant instructions for use.
031
WARNING
Risk of patient injury
A vacuum can be created in the breathing sys-
tem and in the patient's lung if the side open-
ings on the receiving system are covered.
Always make sure that the side openings on
the receiving system are not blocked.
E
E
F
G
H
024
A
B
