Technical data
418
Instructions for use Zeus Infinity Empowered SW 2.n
Monitoring specifications
BISx pod
Connections Pod COM: for connecting to Zeus IE
Sensor cable
Dimensions (H x W x D) 114.5 x 95.3 x 63.5 mm
Weight 227 g
Temperature range, operation:
Temperature range, storage:
10 °C to 40 °C
–20 °C to 40 °C
Relative air humidity, operation:
Relative air humidity, storage:
20 % to 90 %, non-condensing
20 % to 90 % (with packaging)
Air pressure, operation:
Air pressure, storage:
525 to 795 mmHg (70 to 106 kPa)
375 to 795 mmHg (50 to 106 kPa)
Electrical specifications Type BF as per IEC 60601-1
Defibrillation protection according to IEC 60601-2-26
ECG
Display Up to 3 leads
Leads for adults and pediatric I, II, III, aVR, aVL, aVF, V, V+, (aVR/aVL/aVF/V
only with five-lead wire set.
V+ only with six-lead wire set)
Leads for neonates I, II, III, aVR, aVL, aVF, V, V+, (aVR/aVL/aVF/V
only with five-lead wire set.
V+ only with six-lead wire set
Measuring range 15 to 300 bpm
Accuracy ±2 bpm or ±1 %
QRS detection Amplitude: 0.5 to 5.0 mV
Duration: 70 to 120 ms (adult and children); 40 to
120 ms (neonates)
