Instructions for use Zeus Infinity Empowered SW 2.n 419
Technical data
Frequency ranges Filter = Monitor: 0.5 to 40 Hz
Filter = ESU: 0.5 to 16 Hz
Filter = OFF: 0.05 to 40 Hz
Electrical specifications Type CF as per IEC 60601-1
Defibrillation protection according to IEC 60601-2-27
Arrhythmia detection Only for adults and children; not for neonates
Pacemaker detection For adults and children on leads I, II and III, not for
neonates
Pacemakers with the following features can be de-
tected
Amplitude ±2 to ±700 mV
Width (dp) 0.2 to 2.0 ms
Rise/fall (min) 0.1 dp, 100 ms
Overshoot (min) 0.025 ap, 2 mV
Recharge constant 4 to 100 ms
ST segment analysis
Leads for the analysis 3-lead wire set: I, II, III (one lead selectable)
5-lead wire set: I, II, III, aVR, aVL, aVF or V (three
leads selectable without ST option, all leads with
ST option)
6-lead wire set: I, II, III, aVR, aVL, aVF, V or V+
(three leads selectable without ST option, all leads
with ST option)
Isoelectric point Setting range: Start of the QRS complex up to ref-
erence point
Basic setting: Start of the QRS –28 ms
ST measuring point Reference point up to end of the QRS complex
Basic setting: End of the QRS +80 ms
ST complex Length: 892 ms (225 units)
Frequency response: 0.05 to 40 Hz
Update interval 15 seconds, with at least one normal beat
Trend time (ST display) 30 minutes
Trend resolution One data point every 30 seconds
Duration of the ST alarm OFF, 15, 30, 45, 60 seconds
ECG (Cont.)
