Instructions for use Zeus Infinity Empowered SW 2.n 225
Monitoring
Invasive blood pressure measurement
IBP
Signals for invasive blood pressure monitoring
(IBP) are received via a Y-cable, one or more he-
modynamic modules or via a combination of these
devices.
A pressure transducer converts pressures into
electronic signals for the Zeus IE.
These pressure signals are filtered to eliminate ar-
tefacts.
Zeus IE detects individual beats by calculating
threshold values from the running average of the
systolic and diastolic pressures.
IBP parameters
Par. Pressure Measured value Measuring range
ART Arterial Systolic, diastolic, mean –50 to 400 [mmHg]
LV Left ventricular Systolic, diastolic, mean
PA Pulmonary arterial Systolic, diastolic, mean –50 to 400 [mmHg]
RV Right ventricular Systolic, diastolic, mean
CVP Central venous Medium
RA Right atrial Medium
LA Left atrial Medium
ICP Intracranial Medium
GP1 Unspecific, 1 Systolic, diastolic, mean –50 to 400 [mmHg]
GP2 Unspecific, 2 Systolic, diastolic, mean
