System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 6-29
6.3.1.12.9 MPC5553: Pad Configuration Register 47 (SIU_PCR47)
The SIU_PCR47 register controls the pin function, direction, and static electrical attributes of the
DATA[19]_FEC_RX_CLK_CAL_DATA[3]_GPIO[47] pin.
Figure 6-22. MPC5553: DATA[19]_FEC_RX_CLK_CAL_DATA[3]_GPIO[47]
Pad Configuration Register (SIU_PCR47)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x009E Access: Read / write[3:11, 14:15]
0123456789101112131415
R 000
PA
1
1
CAL_DATA[3] is for calibration only.
OBE
2
2
When configured as DATA[19], FEC_RX_CLK, or CAL_DATA[3], the OBE bit has no effect. When configured as GPO, set the
OBE bit to 1.
IBE
3
3
When configured as DATA[19], FEC_RX_CLK, CAL_DATA[3], or GPO, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
4
4
When configured as DATA[19] or CAL_DATA[3], clear the ODE bit to 0.
HYS
5
5
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
6
6
Refer to the EBI section for weak pullup settings when configured as DATA[19] or CAL_DATA[3].
WPS
6
W
RESET: 000000001100001 1
Table 6-21. PCR47 PA Field Definition
PA Field Pin Function
0b000 GPIO[47]
0b001 DATA[19]
0b010 FEC_RX_CLK
0b011 Reserved
0b100 CAL_DATA[3]
1
1
For calibration only.
