System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-40 Freescale Semiconductor
6.3.1.12.20 MPC5553: Pad Configuration Register 58 (SIU_PCR58)
The SIU_PCR58 register controls the pin function, direction, and static electrical attributes of the
DATA[30]_FEC_RXD[2]_CAL_DATA[14]_GPIO[58] pin.
Figure 6-33. MPC5553: DATA[30]_FEC_RXD[2]_CAL_DATA[14]_GPIO[58]
Pad Configuration Register (SIU_PCR58)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x00B4 Access: Read / write[3:11, 14:15]
0123456789101112131415
R 000
PA
1
1
CAL_DATA[14] is for calibration only.
OBE
2
2
When configured as DATA[30], FEC_RXD[2], or CAL_DATA[14], the OBE bit has no effect. When configured as GPO, set the
OBE to 1.
IBE
3
3
When configured as DATA[30], FEC_RXD[2], CAL_DATA[14], or GPO, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clearing the IBE bit to 0 reduces power consumption. When configured as GPI, set the IBE to 1.
DSC ODE
4
4
When configured as DATA[30] or CAL_DATA[14], clear the ODE bit to 0.
HYS
5
5
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
6
6
Refer to the EBI section for weak pullup settings when configured as DATA[30] or CAL_DATA[14].
WPS
6
W
RESET: 000000001100001 1
Table 6-32. PCR58 PA Field Definition
PA Field Pin Function
0b000 GPIO[58]
0b001 DATA[30]
0b010 FEC_RXD[2]
0b011 Reserved
0b100 CAL_DATA[14]
1
1
For calibration only.
