6.3.1.12.19 MPC5553: Pad Configuration Register 57 (SIU_PCR57)
The SIU_PCR57 register controls the pin function, direction, and static electrical attributes of the
DATA[29]_FEC_RXD[1]_CAL_DATA[13]_GPIO[57] pin.
Figure 6-32. MPC5553: DATA[29]_FEC_RXD[1]_CAL_DATA[13]_GPIO[57]
Pad Configuration Register (SIU_PCR57)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x00B2 Access: Read / write[3:11, 14:15]
0123456789101112131415
R 000
PA
1
1
CAL_DATA[13] is for calibration only.
OBE
2
2
When configured as DATA[29], FEC_RXD[1], or CAL_DATA[13], the OBE bit has no effect. When configured as GPO, set the
OBE bit to 1.
IBE
3
3
When configured as DATA[29], FEC_RXD[1], CAL_DATA[13], or GPO, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
4
4
When configured as DATA[29] or CAL_DATA[13], clear the ODE bit to 0.
HYS
5
5
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
6
6
Refer to the EBI section for weak pullup settings when configured as DATA[29] or CAL_DATA[13].
WPS
6
W
RESET: 000000001100001 1
Table 6-31. PCR57 PA Field Definition
PA Field Pin Function
0b000 GPIO[57]
0b001 DATA[29]
0b010 FEC_RXD[1]
0b011 Reserved
0b100 CAL_DATA[13]
1
1
For calibration only.
