Refer to Table 6-16 for bit field definitions. Table 6-40 lists the PA field values for the MPC5553 PCR73.
6.3.1.12.36 MPC5554: Pad Configuration Register 73 (SIU_PCR73)
The SIU_PCR73 register controls the pin function, direction, and static electrical attributes of the
BG_GPIO[73] pin.
Figure 6-48. MPC5554: BG_GPIO[73] Pad Configuration Register (SIU_PC73)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.37 MPC5554: Pad Configuration Register 74 (SIU_PCR74)
NOTE
The MPC5553 does not implement PCR74, therefore this register is
reserved on the MPC5553.
The SIU_PCR74 register controls the pin function, direction, and static electrical attributes of the
BB_GPIO[74] pin.
Table 6-40. MPC5553: PCR73 PA Field Definition
PA Field Pin Function
0b000 GPIO[73]
0b001 CAL_ADDR[11]
1
0b010 FEC_MDIO
0b011 CAL_ADDR[11]
1
0b100 CAL_CS[3]
1
1
For calibration only.
Address: Base + 0x00D2 Access: Read / write[5:11, 14:15]
0123456789101112131415
R 00000
PA OBE
1
1
When configured as BG, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as BG or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clearing the IBE
bit to 0 reduces power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
3
3
When configured as BG, and external master operation is enabled with internal arbitration, clear the ODE bit to 0.
HYS
4
4
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
5
5
Refer to the EBI section for weak pullup settings when configured as BG.
WPS
5
W
RESET: 000000000000001 1
