6.3.1.12.50 Pad Configuration Register 94 (SIU_PCR94)
The SIU_PCR94 register controls the pin function, direction, and static electrical attributes of the
SINA_PCSC[2]_GPIO[94] pin. The SINA function is only available on the MPC5554. Although the
SINA function is not available in the MPC5553, this register enables the selection of the PCSC[2] or GPIO
function for the MPC5553.
Figure 6-62. SINA_PCSC[2]_GPIO[94] Pad Configuration Register (SIU_PCR94)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.51 Pad Configuration Register 95 (SIU_PCR95)
The SIU_PCR95 register controls the pin function, direction, and static electrical attributes of the
SOUTA_PCSC[5]_GPIO[95] pin. The SOUTA function is only available on the MPC5554. Although the
SOUTA function is not available in the MPC5553, this register enables the selection of the PCSC[5] or
GPIO function for the MPC5553.
Figure 6-63. SOUTA_PCSC[5]_GPIO[95] Pad Configuration Register (SIU_PCR95)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x00FC Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA
1
1
The SINA function is only available on the MPC5554; it is not available on the MPC5553. Therefore, set the PA field value for
0b01 or 0b11 only on the MPC5554. Valid MPC5553 PA settings are 0b10 for the PCSC[2] or 0b00 for GPIO.
OBE
2
2
When configured as SINA or PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
3
3
When configured as SINA, PCS, or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear
the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
Address: Base + 0x00FE Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA
1
1
The SOUTA function is only available on the MPC5554; it is not available on the MPC5553. Therefore, set the PA field value
for 0b01 or 0b11 only on the MPC5554. Valid MPC5553 PA settings are 0b10 for the PCSC[5] or 0b00 for GPIO.
OBE
2
2
When configured as SOUTA or PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
3
3
When configured as SOUTA, PCS, or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear
the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
