System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-58 Freescale Semiconductor
6.3.1.12.48 Pad Configuration Register 92 (SIU_PCR92)
The SIU_PCR92 register controls the pin function, direction, and static electrical attributes of the
RXDB_PCSD[5]_GPIO[92] pin.
Figure 6-60. RXDB_PCSD[5]_GPIO[92] Pad Configuration Register (SIU_PCR92)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.49 Pad Configuration Register 93 (SIU_PCR93)
The SIU_PCR93 register controls the pin function, direction, and static electrical attributes of the
SCKA_PCSC[1]_GPIO[93] pin. The SCKA function is not available in the MPC5553 (this register allows
selection of the PCSC[1] and GPIO functions).
Figure 6-61. SCKA_PCSC[1]_GPIO[93] Pad Configuration Register (SIU_PCR93)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x00F8 Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as RXDB or PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as RXDB or PCS or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear
the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
Address: Base + 0x00FA Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA
1
1
The SCKA function is not available on the MPC5553. Do not select 0b01 or 0b11 for the PA field.
OBE
2
2
When configured as SCKA, set the OBE bit to 1 for master operation, or clear the OBE bit to 0 for slave operation. When
configured as PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
3
3
When configured as SCKA in slave operation, set the IBE bit to 1. When configured as SCKA in master operation, PCS, or
GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the IBE to 0 to reduce power
consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
