System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 6-63
6.3.1.12.58 Pad Configuration Register 102 (SIU_PCR102)
The SIU_PCR102 register controls the pin function, direction, and static electrical attributes of the
SCKB_PCSC[1]_GPIO[102] pin.
Figure 6-70. SCKB_PCSC[1]_GPIO[102] Pad Configuration Register (SIU_PCR102)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.59 Pad Configuration Register 103 (SIU_PCR103)
The SIU_PCR103 register controls the pin function, direction, and static electrical attributes of the
SINB_PCSC[2]_GPIO[103] pin.
Figure 6-71. SINB_PCSC[2]_GPIO[103] Pad Configuration Register (SIU_PCR103)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x010C Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as SCKB, set the OBE bit to 1 for master operation, and clear it to 0 for slave operation. When configured as
GPO, set the OBE bit to 1.
IBE
2
2
When configured as SCKB in slave operation set the IBE bit to 1. When configured as SCKB in master operation or PCS or
GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the IBE to 0 to reduce power
consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
Address: Base + 0x010E Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as SINB, clear the OBE bit to 0. When configured as PCS, set the OBE bit to 1.
IBE
2
2
When configured as SINB or PCS, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the IBE
to 0 to reduce power consumption.
When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
