System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-64 Freescale Semiconductor
6.3.1.12.60 Pad Configuration Register 104 (SIU_PCR104)
The SIU_PCR104 register controls the pin function, direction, and static electrical attributes of the
SOUTB_PCSC[5]_GPIO[104] pin.
Figure 6-72. SOUTB_PCSC[5]_GPIO[104] Pad Configuration Register (SIU_PCR104)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.61 Pad Configuration Register 105 (SIU_PCR105)
The SIU_PCR105 register controls the pin function, direction, and static electrical attributes of the
PCSB[0]_PCSD[2]_GPIO[105] pin.
Figure 6-73. PCSB[0]_PCSD[2]_GPIO[105] Pad Configuration Register (SIU_PCR105)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x0110 Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as SOUTB or PCS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as SOUTB or PCS or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register.
Clear the IBE to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
Address: Base + 0x0112 Access Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
When configured as PCSB[0], the OBE bit has no effect. When configured as PCSD[2], set the OBE bit to 1 for master
operation, and clear it to 0 for slave operation. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as PCS or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clear the IBE
to 0 to reduce power consumption. When configured as GPI, set the IBE bit to 1.
00
ODE HYS SRC WPE WPS
W
RESET: 0000000000000011
