Figure 6-100. ETPUB[19]_PCSA[4]_GPIO[166] Pad Configuration Register (SIU_PCR166)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.89 MPC5554: Pad Configuration Register 167–178 (SIU_PCR167–SIU_PCR178)
NOTE
The MPC5553 does not implement PCR167–178. These registers are
reserved in the MPC5553.
The SIU_PCR167–SIU_PCR178 registers control the pin function, direction, and static electrical
attributes of the ETPUB[20:31]_GPIO[167:178] pins. Both the inputs and outputs of ETPUB[20:31] are
connected to these pins.
Figure 6-101. MPC5554: ETPUB[20:31]_GPIO[167:178]
Pad Configuration Register (SIU_PCR167–SIU_PCR178)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x018C Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
The OBE bit must be set to 1 for ETPUB[19] or GPIO[166] when configured as outputs. When configured as PCS, the OBE bit
has no effect.
IBE
2
2
When configured as ETPUB or GPIO outputs, or configured as PCS, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for ETPUB[19] or
GPIO[166] when configured as inputs.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the ETPUB[19] pin is determined by the WKPCFG pin.
Address: Base + 0x018E through Base + 0x01A4 Access: Read / write[5:7, 10:15]
0123456789101112131415
R 00000
PA OBE
1
1
The OBE bit must be set to 1 for ETPUB[20:31] or GPIO[167:178] when configured as outputs.
IBE
2
2
When configured as ETPUB or GPIO outputs, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register.
Clear the IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for ETPUB[20:31] or GPIO[167:178] when
configured as inputs.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the ETPUB[20:31] pins is determined by the WKPCFG pin.
