System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-78 Freescale Semiconductor
6.3.1.12.87 MPC5554: Pad Configuration Register 165 (SIU_PCR165)
NOTE
The MPC5553 does not implement PCR165. This register is reserved in the
MPC5553.
The SIU_PCR165 register controls the pin function, direction, and static electrical attributes of the
ETPUB[18]_PCSA[3]_GPIO[165] pin. Both the input and output channel of ETPUB[18] are connected
to the pin.
Figure 6-99. MPC5554: ETPUB[18]_PCSA[3]_GPIO[165] Pad Configuration Register (SIU_PCR165)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.88 Pad Configuration Register 166 (SIU_PCR166)
NOTE
The MPC5553 does not implement PCR166. This register is reserved in the
MPC5553.
The SIU_PCR166 register controls the pin function, direction, and static electrical attributes of the
ETPUB[19]_PCSA[4]_GPIO[166] pin. Both the input and output channel of ETPUB[19] are connected
to the pin.
Address: Base + 0x018A Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
The OBE bit must be set to 1 for ETPUB[18] or GPIO[165] when configured as outputs. When configured as PCS, the OBE bit
has no effect.
IBE
2
2
When configured as ETPUB or GPIO outputs, or configured as PCS, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for ETPUB[18] or
GPIO[165] when configured as inputs.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the ETPUB[18] pin is determined by the WKPCFG pin.
