System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 6-77
Figure 6-97. MPC5554: ETPUB[16]_PCSA[1]_GPIO[163] Pad Configuration Register (SIU_PCR163)
Refer to Table 6-16 for bit field definitions.
6.3.1.12.86 MPC5554: Pad Configuration Register 164 (SIU_PCR164)
NOTE
The MPC5553 does not implement PCR164. This register is reserved in the
MPC5553.
The SIU_PCR164 register controls the pin function, direction, and static electrical attributes of the
ETPUB[17]_PCSA[2]_GPIO[164] pin. Both the input and output channel of ETPUB[17] are connected
to the pin.
Figure 6-98. MPC5554: ETPUB[17]_PCSA[2]_GPIO[164] Pad Configuration Register (SIU_PCR164)
Refer to Table 6-16 for bit field definitions.
Address: Base + 0x0186 Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
The OBE bit must be set to 1 for both ETPUB and GPIO when configured as outputs. When configured as PCS, the OBE bit
has no effect.
IBE
2
2
When configured as ETPUB or GPIO outputs, or configured as PCS, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for both ETPUB
and GPIO when configured as inputs.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the ETPUB[16] pin is determined by the WKPCFG pin.
Address: Base + 0x0188 Access: Read / write[4:7, 10:15]
0123456789101112131415
R 0000
PA OBE
1
1
The OBE bit must be set to 1 for both ETPUB[17] and GPIO[164] when configured as outputs. When configured as PCS, the
OBE bit has no effect.
IBE
2
2
When configured as ETPUB or GPIO outputs, or configured as PCS, set the IBE bit to 1 to reflect the pin state in the
corresponding GPDI register. Clear the IBE to 0 to reduce power consumption. The IBE bit must be set to 1 for both ETPUB[17]
or GPIO[164] when configured as inputs.
00
ODE HYS SRC WPE WPS
W
RESET: 000000000000001U
3
3
The weak pullup/down selection at reset for the ETPUB[17] pin is determined by the WKPCFG pin.
